ColorBright™️ UV Ultraviolet Series LED Strip Light
Introduction:
Our newly reinvented ColorBright™ Ultraviolet LED Strip Light provides the highest-quality, violet-like glow on the market. Unlike traditional UV fixtures, their compact UV-A technology makes them 100% safe and eye-friendly for everyday practical and decorative applications.
This solution is ideal for residential spaces seeking a beautiful splash of purple or mauve through indirect accent lighting, cove lighting, under-counter lights, or toe kicks. It's also an excellent choice for creating an intriguing and sophisticated ambiance in commercial locations such as bars, restaurants, entertainment venues, and clubs.
Engineered to accommodate most traditional UV-responsive uses, this strip light ensures that blacklight paint and pigments in art installations and nightlife settings shine brightly. Other applications include fishing, germ detection, and the inspection of bills, minerals, or equipment.
Top Features and Benefits:
-
✔ 15-year Warranty
-
✔ 50,000 Hour Lifespan (8 hours a day for 17 years)
-
✔ Thermally resistant 3M VHB 4930 adhesive
-
✔ Fully dimmable
-
✔ Short LED pitch of 1/4" (7 mm)
-
✔ Single BIN LED selection to ensure color consistency
-
✔ UL Listed
-
✔ Highest quality components packaged 3528 SMD LEDs
-
✔ 120° beam angle
Applications and Uses:
These strips are installed in a wide variety of applications including:
-
• Used with blacklight paint
-
• Checking for counterfeit bills
-
• Bar and club lighting
-
• Christmas and holiday lighting
-
• Chemical curing
-
• Rock hunting
-
• Stage lighting
-
• Fishing boats
-
• Inspection of equipment
Why Choose ColorBright™️ UV Ultraviolet Series LED Strip Light:
Specifications:
- ✔ 3 Watts/ft
- ✔ 15-year warranty
- ✔ 50,000-hour lifespan (8 hours/day for 17 years)
- ✔ 3/8" (10 mm) strip width
- ✔ Fully dimmable
- ✔ 120° Beam Angle
- ✔ 24V DC input voltage (12V special order)
- ✔ 36 LEDs/Foot (120/Meter)
- ✔ Can be cut every 2" (50 mm)
- ✔ Short LED pitch of 1/4" (7 mm)
- ✔ Thick double layer 4oz copper PCB
- ✔ Single BIN LED selection to ensure color consistency
- ✔ Maximum Run Length in series 32ft 10in (10 Meters)
- ✔ Highest quality premium packaged 3528 SMD LEDs
- ✔ Ambient Temperature: -4°F - 113°F (-20°C - 45°C)
- ✔ Height: 1/16" (2 mm)
- ✔ UL Listed
Certifications:
Compatible Products:
Aluminum Channels
Compatible Aluminum Mounting Channels
Controllers and Home Automation
Compatible Controllers
Connectors
Solderless Grip Connectors
Power Supplies
Non Dimmable Drivers
Flexfire LEDs® Plug-in Power Supply
Mean Well™ HLG and LPV Hardwired Power Supplies
Dimmable Drivers
Zurik® Universal Dimmable Driver
Zurik® EMLV Dimmable LED Driver
Lutron Hi-Lume Dimmable Driver
ColorBright™ Ultraviolet Series FAQ:
Q: What are the top 4 comparing factors to look for before purchasing LED strip lights?
Understanding these key considerations when buying LED strips is crucial for a successful lighting setup:
1. Make sure you know the requirements for your project, then when looking at options, compare lumen output, CCT, and CRI.
2. Compare LED strip size and number of chips on the reel.
3. Understand the wattage and voltage that the LED strip light uses.
4. Make sure that the products have verifiable quality.
Q: What is the importance of UL Listed?
UL is an acronym for the Underwriters Laboratories. They are an independent product safety certification organization. A good summary used by UL is, "a not-for-profit organization dedicated to public safety." This means you can install these LEDs in commercial spaces, industrial applications, and in your home with peace of mind.
Q: What is the product warranty?
We’re so happy with the quality of our product, we offer a 15-year warranty on most of our LED strips to all our clients.
Q: What is the lifespan of your strip lights?
Our lights have been rigorously tested and have an expected lifespan of 50,000 hours before dropping to 70% luminosity. This means that if you were to use your lights 12 hours a day, every day, the lights would be expected to last longer than 10 years. Even after that time has elapsed, the lights will maintain a brightness of 70%. Higher-output strips require a heat sink to reach the expected lifespan and beyond.
Q: Can UV strips be used for showing markers on bills and checks?
UV strip lights have multiple uses, one of them is showing markers on bills and checks.
Q: What is the UV strip light peak?
The UV strip light peaks between 390 and 400 nm.
Q: What is a 3528 SMD LED chip?
3528 SMD (Surface Mounted Diode) represents the size of the LED chips on the strip. A 3528 SMD chip measures at 3.5mm x 2.8mm. Click here for more information on LED chip sizes.
Q: How do I mount the lights?
The 3M double sided adhesive that is found on the back of the LED strip allows you to install them in most locations. Be sure to thoroughly clean the surface to remove all dust and particulate matter before mounting the strip. Certain surfaces may require you to take additional measures to secure the strips lights into place. Feel free to call us with any questions.
Q: Can I cut the strips myself?
Yes, LED strips are made to be cut to your desired length. Using sharp scissors, you can cut the strip every 2 inches on the designated cut mark. Check out the spec sheet in the Downloads section for more information.
Q: What do I need to turn on my lights?
To turn on LED strips, you will need to connect to a LED power supply. For connecting strips to the power supply we recommend soldering to make the strongest connections. Another option is to use our solderless connectors, which is a faster and easier way to install LED strips.
More Information on LED Strip Lights:
Top 4 "need to know facts" about LED strip lights before purchasing - With a wide range of quality and price points in the market, it is important to educate yourself before buying. 90% of our customers found this page useful in selecting their LED strips
LED Strip Lighting Examples - The versatility of LED strips can be seen in the variety of projects our clients have completed. Looking for ideas?
Need assistance with your project or purchase? Our design specialists are ready to help.
Downloads:
Installation Guide
General LED Strip Installation Guide
Specification Sheet
Ultraviolet LED Strip Light Data Sheet
Connection Guide
Solderless Connectors Installation Guide
IES Files and LDT Files
